Manufacturer's Part #: Milbank UAP2124-O-HSP

4T 320A Aluminum Enclosure

• Brand Name	Milbank
  Type	Ringless Meter Socket
  Application	Meter Socket
  Standard	UL Listed;Type 3R
  Voltage Rating	600 Volts Alternating Current
  Amperage Rating	320 Continuous Ampere
  Phase	1 Phase
  Frequency Rating	60 Hertz
  Size	5.75L x 16W x 30H
  Number of Main Breakers	0
  Main Breaker Size	No Main Breaker
  Cable Entry	Underground
  Terminal	3/8 Inch Stud
  Insulation	Glass Polyester
  Mounting	Surface Mount
  Material	Aluminum with Powder Coat Finish
  Number of Jaws	4 Terminal
  Bypass Provision	Lever Bypass
  Number of Meter Positions	1 Position
  Equipment Ground	2 Barrel Ground Lug
  Hub/Closing Plate	Plain Top
  Number Of Receptacles	0
  Height	30 IN
  Length	5.75 IN
  Width	16 IN

Milbank- Specs Information & Diagram
